Coral-FLT = Setting & FAQ =

Effect files are not included in a present F-15 V1.00 file ( our original ).
We plan to add Effects with F-15 V2.00.

< Japanese >

現行のF-15 V1.00ファイルにはEffectファイルは含まれていません。
（Coral-FLTオリジナルファイル）
アフターバーナー等のEffectファイルはF-15 V2.00で追加予定となっています。

Installation Trouble

Please check the following point, when Gauges are not normally displayed on a panel.

1: Is the Gauges file(***.cab) copied to FS GAUGES folder correctly?

2: Please check the installed path.

O... MS Flight Simulator/GAUGES/***.cab
X... MS Flight Simulator/GAUGES/gauges/***.cab

< Japanese >

パネル上に計器が正常に表示されない場合は、次の点を確認して下さい。

1:計器ファイル（***.cab)は正しくFSのGAUGESフォルダへ
コピーされていますか？

2:インストール先のパスを確認して下さい。

O... MS Flight Simulator/GAUGES/***.cab
X... MS Flight Simulator/GAUGES/gauges/***.cab

Fuel Consumption
( for F-15 VC Model )

We are investigating whether and how we can reproduce Fuel Consumption specific of real fighter aircrafts ( such as F-15 ) in FS more better.

Therefore, we suggest two types of configuration value for Fuel Consumption, please take which you like better. It's your choice.

1: If you want to use AUGMENTOR(also known as AFTER BURNER).......Appropriate configuration for consumption in MACH speed flight.

fuel_flow_scalar=2.900000

( Search [GeneralEngineData] section in "Aircraft.cfg", CORAL_FLT. original distribution. )

* This value will make the cruising range shorter.
However, fuel consumption for maximum speed and Mach flight will be better than real F-15.

2: If you prefer longer cruising ranges.....

fuel_flow_scalar=1.700000

( [GeneralEngineData] section in "Aircraft.cfg" )

According to the official release data from JASDF/USAF, cruising range of F-15 ( with three fuel tanks, no CFT ) is about 4000-4600km ( 2500-2900 miles ).

Distance from Los Angels to New York is about 4600km( 2900 miles ), so we flew from LA to NY for fuel consumption test, then we got appropriate value with flying at FL320/Mach 0.8.
( *AP ALT HOLD armed, FS speed: x16, no consideration about taking off, climbing, descending, and landing )

* fuel consumption for maximum speed and Mach flight will be much better than real F-15.

Japanese

Airspeed

Two kinds of Airspeeds can be displayed by FS setting. ( IAS or TAS)
Please set up IAS for F-15 ( or other fighter aircrafts ).

Originally, the Airspeed of F-15 receives restriction by CAS (or Mach).
( Ex.) Max speed CAS 800kts ( Clean configuration)
However, in FS, it becomes CAS = IAS.

CAS (Calibrated Airspeed) IAS (Indicated Airspeed) TAS (True Airspeed)

<Japanese>

FSでは設定により、2種類の速度を表示することができます。( IAS or TAS)
F-15のような戦闘機用には、IAS で設定して下さい。

本来、F-15の速度はCAS(又はMach)による制限を受けます。
（例) 最大運用速度 CAS 800kts （クリーン状態）
しかしFSでは、CAS = IAS となります。

CAS(較正対気速度)　IAS(指示対気速度）　TAS(真対気速度）

" Airspeed " Setting

FS2002 AI Landing Probrem

When AI F-15 Somtimes fail in landing on FS2002,
please rewrite the following section of Aircraft.cfg.
It is temporary correspondence.
It does not know whether failure can be prevented completely.
* When using it as AI , we recommend you the former V/C-less version.

Japanese

Non-V/C Model Download : FlightSim.com / AVISM Online

[contact_points]
point.0=1, 40.00, 0.00, -8.10, 1181.1, 0, 1.442, 55.92, 0.8, 2.5, 0.9, 4.0, 4.0, 0, 0.0, 0.0
point.1=1, -7.75, -8.58, -8.68, 1574.8, 1, 1.442, 0.00, 1.0, 2.5, 0.9, 6.9, 6.9, 2, 0.0, 0.0
point.2=1, -7.75, 8.58, -8.68, 1574.8, 2, 1.442, 0.00, 1.0, 2.5, 0.9, 7.1, 7.1, 3, 0.0, 0.0

point.3=2, -14.17, -47.33, 0.00, 787.4, 0, 0.000, 0.00, 0.0, 0.0, 0.0, 0.0, 0.0, 5, 0.0, 0.0
point.4=2, -14.17, 47.33, 0.00, 787.4, 0, 0.000, 0.00, 0.0, 0.0, 0.0, 0.0, 0.0, 6, 0.0, 0.0
point.5=2, -54.00, 0.00, 2.83, 787.4, 0, 0.000, 0.00, 0.0, 0.0, 0.0, 0.0, 0.0, 9, 0.0, 0.0
point.6=2, 42.67, 0.00, -3.75, 787.4, 0, 0.000, 0.00, 0.0, 0.0, 0.0, 0.0, 0.0, 4, 0.0, 0.0
static_pitch=0.000000
static_cg_height=7.853791
gear_system_type=0

FS2004 GPS
( for F-15 VC Model )
